BioLink™ Bluetooth Wireless Communication

RF data radio networking tools


BioLink Wireless Communication for CBRN International products

Connect your CBRN International instruments and software together with BioLink Bluetooth RF data radio technology.

With BioLink, you can maximize the capabilities your CBRN International instruments. Sensors and samplers can communicate wirelessly with one another, and also with monitoring software installed on a PC.

When combined with a BioLink Bluetooth base station, up to 28 nodes can be accessed at one time.




  • Features
  • Configurations
  • Specifications

Features

Product Features

  • No bulky cables to fail
  • Extends the utility of instruments
  • Instruments are fully mobile
  • Rapid system setup
  • Easy system reconfiguration
  • Lower installed system costs

Configurations

Bluetooth BioLinks Serial Package

Bluetooth BioLink™ Serial Package for Single Remote Device

Part Number: 7000-0003-02

Includes:

  • Set of two (2) serial BioLinks (DB-9 style) with null modem adapters and USB power cables
  • Quick Start Guide
  • Two (2) +5dBi right angle, right hand antenna (400 meter range. Shown above).
  • Two (2) +1dBi Stub Antenna (100 meter range)
  • CD with software and documentation
Bluetooth BioLink Serial/USB Package

Bluetooth BioLink Serial/USB Package for Single Remote Device

Part Number: 7000-0003-03

Includes:

  • One (1) Bluetooth serial adapter with null modem adapter and USB power cable and one (1) USB Bluetooth adapter
  • Quick Start Guide
  • Two (2) +5dBi right angle, right hand antenna (400 meter range. Shown above).
  • Two (2) +1dBi Stub Antenna (100 meter range)
  • CD with software and documentation
Base Stations for Multiple Devices Base Stations for BioLink Wireless Communications

BioLink Base Stations

Available in 7, 14, and 28 Bluetooth connection models (purchase BioLink units separately)

PN 1100-0016-07

BioLink Serial Bluetooth Wireless Device for additional remote devices

Part Number: 1100-0016-07


Part Number: One (1) Serial BioLink, USB power cable and +1dBi Stub Antenna (100 meter range).

PN 1100-0016-10

BioLink USB Bluetooth Wireless Device for additional remote devices
Part Number: 1100-0016-10

Includes: One (1) USB BioLink and +1dBi Stub Antenna (100 meter range).

PN 1100-0016-08

+5dBi Dipole Antenna
(400 meter range)

Part Number: 1100-0016-08

+9dBi Patch Antenna for BioLink Wireless

+9dBi Patch Antenna
(1,000 meter range)

Part Number: 1100-0016-09

Includes separate cable connection.

Notes:

  1. If only 1 remote node (device) is to be used, two data radios are needed: one at the remote node, the second at the PC.
  2. If more than 1 node is to be used with a PC, or direct connection to the Internet, then a base station must be purchased plus one node radio per remote device.

Specifications

Specifications

Multi-Node Bluetooth Base Station
Bluetooth specification: Bluetooth v2.0 + EDR.
Max data transfer rate: 3 MBPS with USB style
921.6 MBPS with RS-232 style
Working distance: +1dBi Dipole Antenna (100 meter range)
+3dBi Dipole Antenna (200 meter range)
+5dBi Dipole Antenna (400 meter range)
+9dBi Patch Antenna with separate cable connection (1,000 meter range)
Operating temperature: -20°C to 70°C
Storage temperature: 40°C to 85°C
Humidity: 90% noncondensing
Size: 76 x 31 x 16 mm (RS-232)
72 x 22 x 10 mm (USB)
Computer OS support (USB only): Windows 2000/XP/Vista; Linux; MAC OS X (MAC OS X driver required)
Approvals: RS-232: CE, FCC, TELEC, MIC USB: CE, FCC, TELEC, KCC,Bluetooth SIG
Multi-Node Bluetooth Base Station
Bluetooth specification: Bluetooth v2.0 + EDR.
Connectivity: Up to 28 nodes
Max data transfer rate: 3 MBPS
Profiles: Serial Port, LAN access, PAN, Dial-up Networking, file transfer
Network protocols:: IPv4, ICMP, ARP, TCP, HTTP, telnet, TFTP, SSH, HTTPS, SSL/TLS, DNS, SCP/SFTP/FTP, syslog, NTP, SMTP, Dynamic DNS
Working distance: : +1dBi Dipole Antenna (100 meter range); +5dBi Dipole Antenna (400 meter range);
+9dBi Patch Antenna with separate cable connection (1,000 meter range)
Operating temperature: 0°C to 50°C
Storage temperature: -30°C to 85°C
Humidity: 90% non-condensing
Size: 203 x 170 x 44 mm
Weight: 1470 gm
Power: 6W at 5V
Security: IP filtering, SSH v2, SSL/TLS, HTTPS, SCP, SFTP
CF port: Flash memory
Logging: Syslog server, CF memory
Management: Windows utility; Web, telnet, serial console
Customization: Python script engine, ELDK v4.0, 2MB internal user space
MBTF: 30.5 years
Approvals: CE, TELEC, FCC
Bluetooth BioLink™ Package for Single Remote Device: One (1) BioLink with null modem for remote device and one (1) USB-powered BioLink for PC.
Quick Start Guide
Two (2) +5dBi Stub Antenna (400 meter range)
Two (2) +1dBi Stub Antenna (100 meter range)
CD with software and documentation
Base Station: Available in 7, 14, and 28 Bluetooth connection models (purchase BioLink units separately)
Data Radio Options: +1dBi Dipole Antenna (100 meter range)
+3dBi Dipole Antenna (200 meter range)
+5dBi Dipole Antenna (400 meter range)
+9dBi Patch Antenna with separate cable connection (1,000 meter range)

CBRN International reserves the right to change specifications without prior notice.
